Servo Motor Adjustable 30mm Frozen Meat Flaker Machine

Name: Servo Motor Adjustable 30mm Frozen Meat Flaker Machine
Brand: JiuYing
Price: 1 USD

Buy cheap Servo Motor Adjustable 30mm Frozen Meat Flaker Machine product

Brand Name : JiuYing

Model Number : JY-25K

Certification : CE

Place of Origin : Guangzhou, China

MOQ : 1 set

Price : USD

Payment Terms : T/T, Western Union, L/C

Supply Ability : 100 set/month

Delivery Time : 2~15 working days after receive the payment

Packaging Details : plywood package

Item : Frozen Meat Flaker Machine

Dimension : 1850*950*1480mm

Cutting Thickness : 1-30mm (adjustable)

Net Weight : 600KG

G.W. : 650KG

220V 3 Phase : Customized

380V : Yes

Portion Function : Yes

Contact Now

Frozen Meat Flaker Machine Automatic In Stock With Portion Function

Application

Ham/bacon slicer refers to the equipment for cutting slices, segments and cuts of steak, ribs, cold meat and other medium and large-sized ingredients through the transmission system and the movement of the knife.

With the excellent portioning cutting function;
It adopts gentle circular blade technology;
Precision screw holding device to control the raw material with tolerance 0.01 mm;
Human Machine Interface is adopted to set slicing parameters;
Servo motor, reducer and blades are connected in direct combination mode to ensure the precision and high efficiency;
The whole machine is made of stainless steel;
Safety is guaranteed by emergency power off system when open the blades cover, discharging channel, and feeding hopper.

Cutting Effect Display

Before-Raw Beef

Servo Motor Adjustable 30mm Frozen Meat Flaker Machine

After-Slice Cut

Servo Motor Adjustable 30mm Frozen Meat Flaker Machine

Specification

Model	JY-17K	JY-21K	JY-25K	JY-36K
Dimension	17007501250mm	17707201270mm	18509501480mm	182012001550mm
Cutting Size	1~32mm	1~32mm	1~32mm	1~32mm
Capacity	155pcs/min	200pcs/min	210pcs/min	220pcs/min
Inlet Size	170*150mm	210*230mm	250*200mm	360*200mm
Power	3.4KW	3KW	4.4KW	5.5KW
Votage	380V	380V	380V	380V
Net Weight	400KG	450KG	500KG	700KG

Biggest feature:

1. Slice materials evenly and smoothly, such as cheese, sausage, meat, root vegetable, etc.
2. the slice thickness is adjustable from 1-30mm.
3. High efficiency, the capacity can be 200 pcs/min.
4. Motor and Blade are imported form Germany.

5. high efficiency feeding system, make the machine more efficiency.
6. Intelligent pneumatic cutting assistant, material slip proof. ensure the high quality of the final product.
7. Intelligent remainder throwing device, Increased utilization of raw materials
8. The tool is directly connected to the gear drive motor, with high power efficiency and reliable safety measures.

We have revelant running video to show you, if you need it welcome to contact us!
